K-1000 Basic KIM-1 power supply, completely enclosed, terminals trip output +5V @ 1.2A, +12V @.01A regulated, +7.5V @.75A, +16V @02A
See also:
History of the TIM in the Jolt
Jolt software
On this page software for the TIM is described.
- DEMON
- Tiny Basic ad Resident Assembler Program
- Focal-65 V3D
...
Images of the Jolt
Above photos by The National Museum of American History.
Photos from https://vinta...
Jolt with a 74154 decoder
The early Jolts were equipped with a 74154 decoder for the glue logic instead of the 74LS00/04/27 of the later and more ...
