KIM-5

The KIM-5 ROM board can hold 8 6540 mask programmable ROMs.
Known are the 3x 6540 Resident Assembler/Editor ($200) and 1x 6540 KIMath (50$)

On this page:


Where is KIM Going?
Richard Simpson, KIM Forum, Kilobaud 1977

One of the questions most frequently asked me was “what are the future plans for KIM?” Most KIM owners are aware that MOS offers a KIM-2 4K RAM expansion board and a KIM-3 8K RAM expansion board. Either of these can be attached directly to a KIM-1. To expand further, a motherboard (KIM-4) must be added and MOS has planned a KIM-5 ROM expansion board, which will hold up to eight MCS6504 (2K by 8) mask-programmed ROMs (the ROMs are not provided with the KIM-5 but must be purchased separately). At present, there are two sets of software which are planned for release in ROMs – KIMath and a resident assembler/editor.

KIMath
KIMath will occupy a single ROM and consists of a set of subroutines for doing floating-point arithmetic. All calculations are done in BCD to avoid the round-off errors which are inherent in binary floatingpoint routines. The subroutine user can specify the precision (in decimal digits) of any calculation. The more precision specified, of course, the longer the computation time. The package will handle a maximum of sixteen decimal digits of precision plus a two digit exponent so numbers in the range of ±1 times 10E±98 can be handled. The subroutines occupy memory locations F800-FFF8 and were written so they could be used with any 650Xbased system – not just KIM. The subroutines include code for addition, subtraction, multiplication, division, square roots, logs, exponents, tangents and arctangents. All the other trig functions can be generated through the use of trigonometric identities. A subroutine is also provided for evaluating user-specified polynomials, so any continuous function can be approximated.The KIMath ROM should be available by the time you read this. If you don’t want to pay $50 for the ROM, the Programming Manual for KIMath is available for $15 and it includes a complete listing of both source and object code. The manual also contains thirtyseven pages of information on using the subroutines, including a worked-out sample application. If you want to use the ROM but balk at paying $80 for the KIM-5 board to hold it, you’ll be happy to know that the 6540 ROM can be attached directly to the KIM address and data busses, although you’ll need a couple of extra ICs to send the right signal to the KIM-1 Decode Enable line. I’ll provide an interface schematic for this in a future issue of the KIM forum.

The Resident Assembler /Editor
To create any large-scale software on a microcomputer, an assembler is a necessity. Industrial microcomputer users can use the crossassemblers available on several commercial timesharing systems, but the expense of going this route is too much for any but the most affluent hobbyist. Thus, the introduction of the KIM resident assembler should facilitate user software generation and make a lot more software available. The assembler and text editor are available as a set of three MCS6540 ROMs – a total of 6K of code. The $150 which MOS charges for the set may seem exorbitant until you realize that you don’t have to buy 6K of RAM to store it in (which would cost as much or more) and you’ll never have to load it or have it clobbered by errant statements in the program you are developing. Like KIMath, the Assembler/ Editor will work on any 650X-based system. Since the program has to do terminal I/O, locations are reserved in memory page zero to contain the address of the terminal input and output routines. These locations are automatically initialized for KIM owners; users of other 6500 systems (JOLT, TIM, Apple, Baby!, OSI, etc.) can preset those locations with the addresses for the device service routines of their own system. The Editor/Assembler occupies the memory space from E000 to F7FF; thus the editor, assembler, and KIMath fit together in the top 8K of memory.The text editor is a standard line-numbered text editor; it provides much the same editing capability you would find in a BASIC system. You can enter or insert new lines, replace old lines, resequence the line numbers, dump the text file to audio cassette or paper tape, list out lines in the file, and locate lines in the file which contain any specified text string. There is also a special command (actually, any command which begins with an X) to allow you to jump to a user-written subroutine so that you can extend the editor’s capabilities to meet your own needs. Naturally, both the editor and assembler require that you have a terminal connected to the serial port on the KIM-1.The assembler is a singlepass assembler; if your source text is on paper tape or audio cassette, you only have to feed it through once. Normally your source text will be in memory and the assembled code is always written to memory. The source code, symbol table, and object code can be located anywhere in memory you wish. You may have several different source files in memory simultaneously. If you have insufficient memory space to store a large source program, you can break it into several segments, store each segment on audio tape, then bring back one segment at a time for assembly. The assembler will assemble the successive segments until it encounters an “END” statement. It will then put out the symbol table and terminate assembly. Although the editor is fairly limited (it has no capability to edit within a given line, for instance) it is quite sufficient for editing assembly language programs. The assembler is very fast and with good error diagnostics. Perhaps its only serious fault is that the printed symbol table is not sorted alphabetically and no crossreferences are given.


MOS 6540 ROM
The MOS Technology 6540 is a 16k (2KByte) ROM. Factory burned. Mask options for specification of chip select equations. 5! chip selects, requires Phi2 6502 system clock. 24 pin, very uncommon for a small ROM.
A strange and uncommon device, AFAIK only used in the KIM-5 Resident Assembler/Editor and early PET computers. Has a bad reputation, and there are many replacement solutions with standard E(E)PROMs for PET computers.
The 6540’s in the KIM-5 Resident Assembler/Editor on a KIM-5 ROM board are in an excellent condition, dumping with the Backbit Pro chip tester was very easy.

MOS Technology 6540 preliminary datasheet 1977




KIM-5 ROM board
The 3 KIM-5 Resident Assembler/Editor ROMs as placed on the KIM-5 ROM board.
Besides the sockets for the ROMs is some glue logic, 2x 74125 buffers, 2x 7485 address decoders, a 7402 TTL IC and some DIP switches.
The KIM-5 ROM board is to be placed in the KIM-4 Motherboard. The manual is not available alas.

KIM-3B

KIM-3B, a 16K memory module with 2114 SRAM ICs.

KIM-3B (Stefan Hamann)

KIM-3B (Stefan Hamann)

KIM-3B

User’s Manual Memory Expansion Module KIM-3B
User’s Manual Memory Expansion Module KIM-3B
post

John Bell PN 80-Z80

Z80 Microcomputer PN 80-Z80








PCB images by Gledn Deas, thanks!

My retro toolchain

Development for my old 8 bit retro SBC’s has become much easier with fast PCs and good tools. All cross development.

What took hours on my KIM-1: load editor form tape -edit source – save on tape (multiple tape files if big) – assemble form tape to tape – load binary from tape – run
can now be done very fast.
Powerful text editors, cross assembler, KIM-1 Simulator, seconds per iteration.

The only slow part remains: me!

More on my favorite toolchain here.

post

PC Tools

Updated December 2020, Linux compilation checked, bugs fixed, online program for comverting binary to wave file.

To aid in the handling of KIM-1 program and dataformats I have written some programs for Windows and Linux (Raspbian), sources included.

KIM-1 simulator
Convert 8 bit hex formats
KIMPaper
KIM Tape WAV to BIN conversion
KIMPoser Tape Convert hex to WAV online
KIM Tape Convert WAV to BIN and BIN to WAV
Pascal-M cross compiler

All programs come with source (Free Pascal Lazarus), compiled for Windows but thanks to Freepascal and Lazarus also compiled and tested on Linux (Ubuntu and Raspberry PI OS).

Convert 8 bit hex formats

A general purpose utility to convert common 8 bit hex and binary formats, such as Intel HEX, Motorola S records, MOS Papertape, hex format, and binary files.

Sources (Freepascal Lazarus).
Convert8bithexformat Setup for Windows, Executables for Ubuntu and Raspberry PI OS
Available formats:
– BIN binary, raw data, no formatting, no information on start address.
– HEX formatted as hex numbers raw data, no start address included.
– IHEX Intel hex 8 bit format, multiple memory block, start address included.
– PAP MOS Technology papertape format, multiple memory blocks, start address included.
– SREC Motorola 8 bit S record, contiguous memory block, start address included.
– A1hex Apple Woz monitor hex format, start address included.
– KIM Tape as used in the KIM-1 Simulator as emulation of audio tape files.

KIM-1 simulator

6502/65C02 CPU emulation, disassembler, TTY, KIM-1 keypad and LEDs.

See the KIM-1 Simulator page for more information.

KIM Paper

Note that the Conver8bitHexFormat program is also capable of converting to and from Papertape format from many more formats.
Originally written for the launch of the MicroKIM, an older version is on the support CD.

When you attach a serial device like the teletype or a modern PC with Hyperterminal you can use the TIM monitor of the KIM-1. One of the functions is loading from and saving to a papertape device on the teletype. Now since this is a way to load and save data as a textfile this is in fact quite useful.
The Micro-KIM triggered me to modernize my conversion utility for MOS Technology papertape format dating from 1983, VAX/VMS and Turbo Pascal. A Windows and a commandline/console version are available.

KIMPAPER for Windows

A program for Windows to convert between papertape and binary format.

Windows setup KIMPAPER
Sources (Freepascal Lazarus, build also on Linux)

KIMPAPER V1.1 for DOS

Not too modern, but handy, a commandline utility. Does exactly the same as the Windows program KIMPAPER. Runs fine in a commandline DOS box. Can also be compiled for Linux with Freepascal. In the KIMPAPER DOS archive the program, source and information on the program and papertape format can be found.

C:\MICROKIM\kimpaper
KIM-1 MOS Technology BIN papertape format conversion utility, Hans Otten, 2007 v1.1

Syntax is:
KIMPAPER [-[b|p] filename [startaddress]
C:\MICROKIM\kimpaper -h
KIM-1 Mos Technology BIN papertape format conversion utility, Hans Otten, 2007 v1.1
Syntax is: KIMPAPER [-[b|p|h] filename [startaddress] first parameter switches
-h help
-p convert to papertape
-b convert to binary
second parameter (first if no parameters, assumed binary to papertape)
name of file to convert
.BIN for binary, forces conversion to PAPertape
.PAP for papertape, forces conversion to BINary
third parameter (assumed 0000 if not present)
startaddress for BIN to papertape conversion
Files of type .BIN wil force conversion to papertape.PAP
Files of type .PAP wil force conversion to binary .BIN

Examples:
C:\MICROKIM\kimpaper mastermind.bin 0200
KIM-1 Mos Technology BIN papertape format conversion utility, Hans Otten, 2007 v1.1
C:\MICROKIM>kimpaper mastermind.pap
KIM-1 Mos Technology BIN papertape format conversion utility, Hans Otten, 2007 v1.1
Start address 0200 in file mastermind.BIN

Convert KIM tape to text


KIM Tape to Text is a utility to convert between binary format of a KIM-1 tape dump to a DOS text file.
The KIM tape dump is a binary file and is just a dump of part of the memory of the KIM-1.
This binary file can be a text file as used in editors Micro Ade or CW Assm/TED.
By using the tape write routine in the KIM-1 one can write an audio file on cassette.
When this audio file is captured on a PC as WAV file (22K, mono) this can be converted back to a binary memory dump with ED’s Utility KIMTape
These text files can be converted to DOS text files with this utility.

First open the binary file. If this is recognized as Micro Ade or CW Moser format, the Save as text file can be used.

Windows program.
Full source for Freepascal and Lazarus, no Windows dependencies. Compiled on 64 bits Windows 10 as 32 bit application.

Note on detection of assembler editor type
1. Micro Ade file must start with CR: when present this is Micro Ade
line nr follows 2 byte
line ends with $0D
file ends with $40
2. Assm/Ted by CW Moser starts with line number $10 $00
end of line is high bit set
There may be rare situations that a file starts with a $0D or a different line nr. You can force CW Mose detection by changing this to a sequence of $10 $00 $0D and if necessary blanks $20 to make it consistent. If in doubts: use an editor that shows the file in hex (Ultra Edit, or the free Notepad ++, Text editor PRO) and study the tape file.

Methods to get the binary file out of a Junior or KIM-1.
Read the record tape into a binary with Ed’s KIMTAPE conversion *see below). It is MS-DOS and runs fine in VDOS (https://www.vdos.info/) or DOsbox (slow).
Make a note of start address as shown by KIMTAPE.
Non-printing ASCII characters are filtered out of the resulting text file.

KIM Tape Convert WAV to BIN and BIN to WAV

Not my program, but so handy!

KIMTAPE v0.5 – tape conversion utility for KIM-1 and SYM-1 (2004-05-17) Local copy of http://dxforth.mirrors.minimaltype.com/#kimtape)

KIMTAPE allows programs stored on cassette tape to be decoded to a program file. It handles both MOS Technology KIM-1 and Synertek SYM-1 tape formats including HYPERTAPE. The reverse process – converting a program file to an audio wavefile is also possible, allowing one to produce perfectly regenerated cassettes. KIMTAPE works with 8-bit mono WAV, VOC or RAW audio files recorded
at 22050 samples per second.

Download: kimtap05.zip (MS-DOS) It is MS-DOS and runs fine in VDOS (https://www.vdos.info/) or DOSbox (slow).

The binary files in the KIM-1 program archives have been reproduced, from the original cassette recordings, with the tool KIMTAPE on a PC in a DOS box. See Eds DX-Forth and Utilities Page for this and other nice programs.
This program also makes it possible to reproduce the original cassette recordings that can be read by a KIM-1.

The files were made as follows: The KIM-1 cassette audio was connected to the PC audio input and (with e.g. Audacity) recorded as a wave file (mono 22KHz).
For example: qchess.wav
The wave file was then converted with KIMTAPE to a binary file (the exact content of of the KIM-1 memory when recorded).
And the KIMTAPE utility then displays load address (for example and tape ID

c:\kimtape qchess.wav qchess.bin
KIMTAPE version 0.5 17-May-04
infile: qchess.wav
outfile: qchess.BIN
Program 01 address 0200 checksum OK xxxx bytes done

This .bin file (any extension is fine!) is NOT a wave file! It contains the exact content of the KIM-1 memory when recorded. The size is exactly the number of bytes as stored in the memory of the KIM-1 and much smaller than the wave file. This binary file can be converted back to a wave file with KIMTAPE or converted to a papertape file with KIMPAPER:

C:\kimtape -M -A0200 -D01 -B2 qchess.bin qchess.wav

As you can see: you have to specify the load address and the program ID. The B parameter indicates hypertape speed (2 here, slow)
The resulting wav file should be acceptable for the KIM-1. It is (as I have tested) acceptable as input for KIMTAPE!

All command parameters can be seen by typing KIMTAPE without parameters:

Pascal-M Cross compiler

Executables of cross compiler, workflow, sources, command line utilities.

post

My retro toolchain

About my toolchains for retro computing.

Tools are very personal choice, what works for me. I use Windows (11 now) as my main workstation and often the command line. I do have Linux desktops for compatibility testing. As I grew up in the 80ties with mini’s like HP1000, PDP-11 + RSX-11M, VAX/VMS, MS-DOS, all command line, many many editors, from line editors to screen oriented (EDT from DEC was great!) with all kind of automation tools and code management, I feel comfortable with what Windows (and Linux) offer me now, it makes me very productive! YMMV, pick your tools as you like it.

Tools development
When there is not a tool available that does easy what I need, I write my own. GUI or command line, depending on the context.
My toolchain consists of Freepascal (commandline) and Lazarus (GUI).
Most tools have to do with manipulating binary data as to be expected. Other areas are compilers and simulators.
Resulting tools run on Windows, Linux and Apple Mac’s. See the, like the Hex format conversion, the KIM-1 Simulator and more.

Assembly toolchain

I have quite a collection of 8 bit computers, 6502, Z80, 6809.
Each processor comes with its own machine language, and for each processor myriads of assemblers have been made, each with its own deviations of the official syntax and way they operate. The simple ones are two-pass assemblers generating binaries and listings and symbol tables. More advanced are made up of an assembler and a linker. Linkers are nice and powerful, but a bit overkill for simple projects. I like command line assemblers, callable from an editor.

Notepad++ Editor
A very powerful text editor, with syntax highlighting, multiple files windows open, good search, plugins like hex editor and external tools support.

  1. Install latest version from the download
  2. Add plugins Hexeditor and NPPEXEC
  3. Add scripts to nppexec such as (requires TASM 2 installed, read below)

    • make6502pap tasm -65 -x3 -g1 -s “$(FILE_NAME)” “$(NAME_PART).pap” “$(NAME_PART).lst” -s “$(NAME_PART).sym”
    • make6502bin tasm -65 -g3 -s -l -fff “$(FILE_NAME)” “$(NAME_PART).bin” “$(NAME_PART).lst” -s “$(NAME_PART).sym”
    • make6502hex tasm -65 -x3 -g0 -s “$(FILE_NAME)” “$(NAME_PART).ihex” “$(NAME_PART).lst” -s “$(NAME_PART).sym”
    • makez80hex tasm -80 -g0 -s “$(FILE_NAME)” “$(NAME_PART).ihex” “$(NAME_PART).lst” -s “$(NAME_PART).sym”
    • etc, see c:\tasm\TASMMAN,HTM
  4. Edit you source
  5. Assembly first time: press F6 choose wanted script
  6. After that Press CTRL-F6 to asemble
  7. The output of the assemble appears at the bottom of the editor in a separate part
  8. Open in Notepad also the listing file
  9. If errors, correct the source
  10. if errorfree, start debugging your code, leave Notepad++ open to edit source and read the listing

TASM32
This is a command line assembler that supports processors like 6502 and Z80. Output is binary, MOS papertape, Intel Hex, Motorola S-record. Listings and symbol tables (for the KIM-1 Simulator) can be generated. Used from Notepad++ as Tool, no need to start from the command line.

  1. Download TASM 32 here
  2. Unpack in e.g. c:\tasm
  3. Create environment variable TASMTABS=C:\TASM
    (Settings – Related Settings – Advanced system settings – Advanced tab – Environment Variables).
  4. Add c:\tasm to the PATH
  5. Invoke tasm from the command line without arguments for help and/or read TASMMAN.HTM in C:/tasm
  6. Add macro’s to Notepad++, see there.

Test and debug
The output of the assembler can be downloaded to the SBC. Burn an EPROM, download hex or papertape. And test the code.

For KIM-1 programs I always use the KIM-1 Simulator debugger on the PC.
Set breakpoints and watches, trace the code, inspect memory, run the program.
When it is a TTY console program, I sue a terminal emulator, Teraterm.
2400 baud 8 bit, one stop bit, no parity, 5 ms character delay, 20 ms line delay for papertape upload.. Higher baudrates may work.

For CP/M there are many emulators available, choose one that allows file from the PC to be accessed also by the emulator. E.g. the Z80 IDE and CP.M emulator of Hein Pragt.
CC65
I only use the assembler and linker of the CC65 package. Mainly for KIM-1 KB9 Basic development, as the source from Pagetable is in this format.

This is how I do it (Windows, can be done also on Linux)

  1. Download and unpack the archive of pagetable in a folder on your PC.
  2. Download and unpack the CC65 package, a C compiler, from which only the assembler and linker is used. I used the Windows binary.
  3. Copy CA65.EXE, LD65.EXE and longbranch.mac from the CC65 package to the folder where you unpacked the MS Basic source.
  4. Change whatever you like in the source. It is quite a complicated construction, with macros for every variant, so look carefully at the listing file what really is produced.
    Start with no adaptations and then go on studying the listing file and testing. The KIM-1 Simulator is a good tool for testing! Load the symbol table file to see what is where.
  5. Assemble and link with this simple batch file makekb9v2.bat, resulting in an object, a binary, a listing file and a symbol label file.
    ca65 -D kb9 msbasic.s -o tmp/kb9v2.o -l tmp/kb9v2.lst
    ld65 -C kb9.cfg tmp/kb9v2.o -o tmp/kb9v2.bin -Ln tmp/kb9v2.lbl

  6. Repeat step 4 and 5 until you are satisfied with the adaptations. The article listed above are a good source of inspiration.

Winmerge
A tool to compare files, text and binary. Open the program, drop binary files from the explorer on it and see the differences highlighted. Essential to compare ROM dumps or to check if assembler source assembly leads to identical binary as the original. Detects subtle syntax differences from sources converted or disassembled, leading to different code.

Disassembler
Still searching for a good multiprocessor tool. With some intelligence, like input files not only binary, but also a symbol file and tips of what is data and what is code. Output should be in assembler format ready to assemble. A multipass operation, where you learn from each iteration symbols and data areas.

For 6502 code I use the online tool at Virtual Disassembler. Drop the binary and copy the code. Choose the output format, like “listing” or “assembler”. You can input a symbol file.

Micro-Professor MPF-1B

New in my collection of SBCs:

Micro-Professor MPF-1B. A Z80 based SBC. Perfect trainer. In very good condition, with Tiny Basic built-in. Complete in original box, Monitor source listing, Multitect powersupply,
German handbook, alas no Basic template.

Works perfect:

More photos here:

post

Micro-Professor MPF-1B

A Z80 based SBC. Perfect trainer. In very good condition, with Tiny Basic built-in. Complete in original box, Monitor source listing, Multitect powersupply,
German handbook, alas no Basic template.

Works perfect:

Documents can be found on the site of Fred Kraan.

John Bell Z80 computer 80-280

I received a photo and manual scans of the 80-280 Z80 SBC by John Bell.

Posted in Z80

Z80 Microprocessor kit

Design and text by Wichit Sirichote. The kit is available for sale, kit or assembled. Wichit picked the Z80 CPU and designed the microcomputer kit with HEX keys and 7-segment LED displays, and wrote the monitor program.The version I have is an older (slower) version with a monitor (source in User manual) close to the the Microprofessor 1b. The current one has a SDCC compiler generated monitor program.
