Here images of Synertek related objects in my collection.
VIM-1 the first version of the SYM-1
First SYM-1 back and front
First SYM-1 back
Second SYM-1
Third SYM-1
First KTM-2/80 front
First KTM-2/80 back
Second KTM-2/80 front. Note the EPROMs
Second KTM-2/80 back, with a 7400 to select the larger EPROM
KTM-2/80. Mote the ’80’ jumper solder bridge.
Corsham RAM/ROM board for AIM 65/SYM-1
Retrospy RAM/ROM board, I/O board, SYMDOS board
SYM-1 Cassettess Tiny Basic 2KAseembler, Power connector
SYM-1 Expansion baord
