RNB Enterprises sold a range of AIM 65/SYM-1/KIM-1 extension cards, ranging from a VAK-1 Motherboard, RAM and EPROM cards anda prototyping card.
Photo by Eric Dennison
 |
VAK-1/2/4 manuals RNB Enterprises User Manual VAK-1 Motherboard Schematics of VAK-1 Motherboard User Manual VAK-2, -3, -4 (2x 8KB SRAM boards) |
Photo by Eric Dennison
Byte Magazine 1979 01 RNB Enterprises SYM-1 KIM-1 VAK-X boards advertisement
 |
Byte Magazine 1979 01 RNB Enterprises SYM-1 KIM-1 VAK-1to VAK-8 boards advertisement |
